Tower Pro MG995 Metal Gear Servo Motor (180 Degree Rotation)
Tower Pro MG995 Metal Gear Servo Motor (180 Degree Rotation) ₹220.00
Back to products
Nylon & Pinned Hinge 12x24 (10pcs)
Nylon & Pinned Hinge 12x24 (10pcs) ₹159.00
Click to enlarge

TowerPro MG996R Digital High Torque Servo Motor

SKU: 166

Tower pro mg996r

₹299.00

20 in stock

20 in stock

Add to wishlist
14 People watching this product now!

Description

Continuous Rotation Servo MG996R, 360 deg.
The Continuous Rotation Servo MG996R has the ability to rotate continuously in 360 degrees at both directions. This makes this servo perfect for robotics or even the rotation of camera sliders!

Specification:

Weight: 55g
Dimension: 40.7?19.7?42.9mm
Stall torque: 9.4kg/cm (4.8v); 11kg/cm (6.0v)
Operating speed: 0.19sec/60degree (4.8v); 0.15sec/60degree (6.0v)
Operating voltage: 4.8 ? 6V
Gear Type: Metal gear
Temperature range: 0- 55deg
Dead band width: 1us
Wire length: 32cm
Aluminum 6061-T6.

Customer Reviews

0 reviews
0
0
0
0
0

Reviews

Clear filters

There are no reviews yet.

Only logged in customers who have purchased this product may leave a review.

Shopping cart
Close
Sign in
Close

No account yet?

Compare
0 Wishlist
0 items Cart
All Categories
Contact

+91 9911-3637-11

Store Locator

visit

Menu
All Categories
0 Wishlist
1 item ₹1,049.00
4in1 30A ESC Board BLHeli_S BLHeli-S 2-56S Output 5V 36cmx36cm for F4 FPV RC Drone Racing Drones Quadcopter Accessories
4in1 30A ESC Board BLHeli_S BLHeli-S 2-56S Output 5V 36cmx36cm for F4 FPV RC Drone Racing Drones Quadcopter Accessories ₹2,462.00
Back to products
UBEC Voltage Converter 5V/7A in INDIA
UBEC Voltage Converter 5V/7A in INDIA ₹345.00
Click to enlarge

Hobbywing 5V 3A Amp Switch Mode DC UBEC

SKU: hw5vubec
  1. Input: 5.5V-26V (2 to 6 cells Lipo battery pack, 5 to 18 cell NiMH battery pack)
  2. Output: 5V/3A and 6V/3A switchable
  3. Ripple: <50mVp-p(@2A/12V)
  4. Continuous current: 3A.
  5. Suitable for: RC AirPlane Multirotor helicopter.
  6. Instantaneous current: Min. 4A 20 seconds.

₹265.00

1 in stock

1 in stock

Add to wishlist
19 People watching this product now!

Description

A UBEC (universal battery eliminator circuit) is purely a device that converts high-voltage (such as 25V from a 6S LiPo) to lower voltages to allow the full UAS to be powered from one primary battery source, The UBEC is a Switch-mode DC regulator separated from ESC (ESC—) Electronic Speed Controller for brushless/brushed motor), it will take high-voltage (5.5V to 26V) power from your battery pack and convert it to a consistent safe voltage for your receiver, gyro and servo.

For traditional speed controller with a build-in BEC, it will very likely have only a limited ability to supply power to your receiver and servo without overheating. if you are using a high-voltage battery pack or have heavy servo load, you should consult the ESC specification to determine what the started recommendations or limitations are. in general if you are using a 4 cell lithium battery pack or more than a 12 cell Nickel based battery pack you should consider using an UBEC because  in such a case the build-in BEC of the ESC can support only 2 servos, which means it is not suitable for RC helicopter and big aircraft.
